Product Highlights

Performance

• Mobile Intel® Pentium® 4 processor-M at 1.80GHz

• 256MB expandable to 1024MB

All-in-one design

• 30GB hard disk drive

• DVD-ROM/CDRW multi-function drive

• 3.5” 1.44MB floppy diskette drive

Great Features

• 15.0” TFT active matrix display

• 16MB nVIDIA GeForce4 420 Go video memory

Get On-Line

• Integrated V.92/56K modem

• Integrated 10/100 Ethernet LAN

System Characteristics

CPU (See CPU Performance Disclaimer)

• Mobile Intel® Pentium® 4 processor-M at 1.80GHz*

• Integrated co-processor

L2 Cache

• 256KB Level 2 Cache integrated in module

• 400MHz front side bus clock speed

Memory

• 256MB expandable to 1024MB; SODIMM expansion memory

• 128/256/512MB PC2100 SDRAM, 2.5V

• Data/Address Bus Width; 64-bit/32-bit

• BIOS ROM: 4Mbit, Intel FWH

• Intel 845MP Chipset

Mass Storage

• Floppy Disk Drive: 3.5”, 1.44MB

• Primary Hard Disk Drive: 30GB hard disk drive; Enhanced IDE

(ATA-5); 9.7mm height, 0.2lbs, 14.3ms average access time

(read/write), 3ms track to track seek time (read/write), supports

PIO mode4, Ultra DMA mode5, Multiword DMA mode2, service

removable

• DVD-ROM/CDRW: Enhanced IDE (ATAPI Interface);

Compatibility: CD-ROM, CD-R (read/write), CD-RW (read/rewrite),

DVD-ROM, DVD-R (read only), supports PIO mode4,,

Multiword DMA mode2, Ultra DMA mode2

• Software Decoder: WinDVD

Graphics/Video

• 15.0”TFT active-matrix display; Internal display supports up to

16M colors at 1024 x 768

• nVIDIA GeForce4 420 Go graphics controller; 16MB internal

video memory

• 3D Graphics Accelerator, AGP bus support; 2D Graphics

Accelerator, BitBLT hardware, Hardware cursor, Direct Draw

support

• External Color Support/Refresh rate:

800 x 600; 60/75/85/100Hz Non-Interlaced @16M

1024 x 768; 60/75/85/100Hz Non-Interlaced @16M

1280 x 1024; 60/75/85/100Hz Non-Interlaced @16M

1600 x 1200; 60/75/85/100Hz Non-Interlaced @16M

1920 x 1440; 60/75Hz Non-Interlaced @16M

2048 x 1536; 60Hz Non-Interlaced @16M

Input Devices

• Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key

stroke, 6mm height; Dedicated Windows. & Application keys

support; HotKey function; TouchPad pointing device w/Wheel;

Scroll function (by help of driver)

• CD Control Function: Play/Pause, Stop/Eject, Previous,

Skip/Next, CD Power

• Instant Access Internet Button

• Toshiba Console Button

Expandability

• 2 Expansion memory slot (including main memory slot); 2 PC

Card slots support 2 Type II or 1 Type III PC Cards; 32-bit

CardBus ready

Communications

• Integrated V.92/56K modem; Data and fax support

• Integrated 10/100 Ethernet LAN

Due to FCC limitations, speeds of 53kbps are the maximum

permissible transmission rates during

Download. Actual data transmission speeds will vary

depending on line conditions.

• ECP Parallel printer port

• RGB Port (Monitor)

• 3 Universal Serial Bus ports

• Infrared port

• TV-Out (NTSC/PAL output; RCA jack)

• RJ-45 LAN port

• RJ-11 modem port

• SD Card

Physical Description

• Dimensions (LxWxH): 12.8” x 11.2 x 1.7”

• Weight: 7.8lbs

• LED Indicators: Power, Power Save Mode, HDD, FDD, CD/DVDROM,

DC-IN, Caps Lock, Arrow, Numeric, Main Battery Charging

Status, System Sleep / Suspend status

• YMF753 Codec Chip; Software Sound Chip

• 16-bit stereo, Built-in stereo speakers

• Direct 3D Sound; DirectSound (supported by driver) and

DirectMusic; Full Duplex and MIDI support

• Sound Volume Control Dial

• Ports: Microphone port, headphone port

Power Supply

• AC Adapter: 75W external AC Adapter, 100-240V / 50-60Hz

frequency (Universal) input voltage, 15V x 5A Output.

Dimensions (LxWxH): 5.5” x 2.2” x 1.1” ”

Weight: 0.88lbs

• Battery Pack: 9-cell, rechargeable, removable Li-Ion battery,

10.8V x 4500mAh = 48.6Wh

Dimension (LxWxH): 6.8” x 2.7” x 0.7”

Weight: 0.8 lbs

• Up to 2.52H battery life; Recharge time (on/off): 3H/4H-11H+

Battery life may vary depending on applications, power

management settings and features utilized.
